Product Details
Place of Origin: Guangdong, China
Brand Name: SME
Certification: CE
Model Number: SME-3150
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Negotiable
Packaging Details: Carton
Air Flow Rate: |
600-1000L/min |
Machine Size: |
1.2M(L)×1.740M(W)×2.4M(H) |
Liquid Tank: |
80L |
Warranty: |
1 Year |
Cleaning Process: |
Cleaning Starts - Diaphragm Pump Pressurization - Liquid Extraction -1UM Filtration - 360-degree Rotary Jet Cleaning - Spray Cleaning -20UM Filtration, Solution Back To The Liquid Tank - Compressed Air 360 Degree Rotary Jet Drying |
Machine Weight: |
560KG |
Air Supply: |
0.5Mpa~ 0.7Mpa |
Power Supply: |
AC380V |
Air Flow Rate: |
600-1000L/min |
Machine Size: |
1.2M(L)×1.740M(W)×2.4M(H) |
Liquid Tank: |
80L |
Warranty: |
1 Year |
Cleaning Process: |
Cleaning Starts - Diaphragm Pump Pressurization - Liquid Extraction -1UM Filtration - 360-degree Rotary Jet Cleaning - Spray Cleaning -20UM Filtration, Solution Back To The Liquid Tank - Compressed Air 360 Degree Rotary Jet Drying |
Machine Weight: |
560KG |
Air Supply: |
0.5Mpa~ 0.7Mpa |
Power Supply: |
AC380V |
The Stencil Cleaning Machine is the perfect choice for those who need to clean their stencils quickly and effectively. This machine is a powerful and efficient cleaning solution that can be used for a variety of applications. It features a filter system of 1m/50um/1um with three levels, an 80L liquid tank, a maximum stencil size of L1500 X W1500 X T60(mm), an air flow rate of 600-1000L/min, and a dry time of 3-5 minutes. The Stencil Washing Device is an ideal choice for any business or individual who wants to easily and quickly clean their stencils with a fast, efficient, and reliable machine. Stencil Washer Machines are perfect for those who want to save time and money while still getting a high-quality cleaning job done.
| Parameter | Description |
|---|---|
| Cleaning method | 360° Double-side Spray Rod Rotating Isobaric Spray Cleaning |
| Liquid tank | 80L |
| Clean time | 3~5min |
| Dry time | 3~5min |
| Filter system | 1m/50um/1um, 3 Level |
| Clean method | Spray Clean + Compressed Air Blow Dry |
| Machine size | 1.2M(L)×1.740M(W)×2.4M(H) |
| Warranty | 1 Year |
| Drying method | 360° Double-side Spray Rod Rotary Compressed Air Drying |
| Cleaning process | Cleaning Starts - Diaphragm Pump Pressurization - Liquid Extraction -1UM Filtration - 360-degree Rotary Jet Cleaning - Spray Cleaning -20UM Filtration, Solution Back To The Liquid Tank - Compressed Air 360 Degree Rotary Jet Drying |
The SME-3150 Stencil Cleaning Machine is ideal for use in a variety of applications, from industrial production processes to precision cleaning operations. It uses an air flow rate of 600-1000L/min to effectively and quickly remove contaminants from stencils, while its 560KG weight makes it easy to move and install. This device is also equipped with a CE certification to ensure quality and safety. With a dry time of 3-5 minutes and a machine size of 1.2M(L)×1.740M(W)×2.4M(H), it is a great choice for anyone needing reliable and efficient stencil washing. The SME-3150 also comes with a 1 year warranty and a minimum order quantity of 1 pcs for a competitive price.
This product is a Stencil Washer Machine, Stencil Washing Device, with brand name SME and model number SME-3150, with a liquid tank of 80L, power supply of AC380V, air supply of 0.5Mpa~ 0.7Mpa, air flow rate of 600-1000L/min, and max stencil size of L1500 X W1500 X T60(mm). It is certified by CE and the minimum order quantity is 1 pcs. The price is negotiable and the packaging material is carton.
If you are looking for a Stencil Cleaning Machine, then you should definitely consider our SME-3150 model. With its high-quality components and reliable performance, you can be sure that your stencils will be thoroughly cleaned quickly and efficiently.
We provide technical support and service to ensure that your Stencil Cleaning Machine is running smoothly and efficiently.
If you need help with your Stencil Cleaning Machine, please contact us today. We look forward to hearing from you.
Packaging and Shipping for Stencil Cleaning Machine:
The Stencil Cleaning Machine will be securely packaged to prevent any damage during transit. It will be shipped in a cardboard box with plenty of bubble wrap and foam to ensure it's safe arrival.
We offer both domestic and international shipping. We use a variety of carriers depending on the destination and the size of the package. All packages are tracked and insured.
