Product Details
Place of Origin: Guangdong, China
Brand Name: SHENHUA
Certification: CE,ISO,UL
Model Number: SME-6200
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Vacuum +plywood case package, case size: 7200*2200*2200 mm(L*W*H)
Delivery Time: 50~60days
Payment Terms: L/C, T/T, D/P, Western Union, Paypal, Money Gram
Supply Ability: 200 sets per Year
Material: |
SUS304 Stainless Steel |
PCBA Size: |
L400*W600*T100mm As Max |
Conveyor Net Width: |
600mm |
Conveyor Speed: |
0.1~1.5m/min |
Conveyor Direction: |
Left To Right |
DI Water Amount: |
400L/H |
Air Exhaust Amount: |
40m³/H |
DI Water Resistivity Range: |
0~18MΩ |
Compressed-air Supply: |
0.5Mpa, 200~400L/min |
Power Supply:: |
AC380V, 3P, 50/60Hz,110KW |
Machine Size: |
6200*1750*1650( L*W*H) Mm |
Machine Weight: |
3000KG |
Material: |
SUS304 Stainless Steel |
PCBA Size: |
L400*W600*T100mm As Max |
Conveyor Net Width: |
600mm |
Conveyor Speed: |
0.1~1.5m/min |
Conveyor Direction: |
Left To Right |
DI Water Amount: |
400L/H |
Air Exhaust Amount: |
40m³/H |
DI Water Resistivity Range: |
0~18MΩ |
Compressed-air Supply: |
0.5Mpa, 200~400L/min |
Power Supply:: |
AC380V, 3P, 50/60Hz,110KW |
Machine Size: |
6200*1750*1650( L*W*H) Mm |
Machine Weight: |
3000KG |
SME-6200 is a SUS304 stainless steel material Deflux 400L DI Water Cost 600mm Width PCBA Cleaning Machine 3000KG Liquid Spray Cleaning Machine. It is a multi-function, high clean performance, new developed PCBA spray technology machine.
SME-6200 is our traditional type which is usde to wash PCBA, semi-conductor, precise medical, car electronics, fixture and lens.
Wash process: Pre-wash+Wash+chemical isolation+ Prerinse+air cut +Rinse+Final rinse+ Air blow dry+ Hot air dry.
SME-6200 advantages:
1. Big quantity PCBA in line cleaning system.
2. Thoroughly clean all kinds of solder paste flux on SMT or THT PCBA after welding.
3. DI water wash sections + DI water rinse section+ Air blow section + hot air dry sections.
4. Fresh DI water supply automatically, post-section DI water overflow to the previous-section to renew DI water.
5. Up/down spary system on wash and rinse sections.
6. Liquid and DI water spray pressure can be adjusted for dirrerent PCBA cleaning requirements.
7. Standard equipped with Resistivity monitoring system, resistivity range 0~18 MΩ.
8. Air knives blow dry section+ hot air dry section.
9. SUS304 stainless PCB flat conveyor net system.
10. PLC control system, English operation interface, easy operation.
11.Many optional functions avalible.
12. Total SUS304 structure, Acid and Alkali corrosion resistance.
Machine Spec:
| S/N | Item | SME-6200 Spec |
| 1 | conyeyor net | 600mm |
| 2 | conveyor speed | 0.1~1.5m/min |
| 3 | conveyor height | 900±50mm |
| 4 | conveyor direction | Left to Right |
| 5 | PCB size | L400*W600mm as max |
| 6 | PCB height | 100mm as max(with component) |
| 7 | wash tank capacity | 280L |
| 8 | rinse tank capacity | 40L+120L |
| 9 | DI water consumption | 400~800L/H |
| 10 | exhausted air | 40m³ |
| 11 | electric control | PLC+TP |
| 12 | Resistivity range | 0~18MΩ |
| 13 | PH range | None |
| 14 | air supply | 0.5Mpa,200~400L/Min |
| 15 | power supply | AC380V,50/60HZ, 3P,110KW |
| 16 | machine size | L6200*W1750*H1650mm |
| 17 | machine weight | 3000KG |
Q1: What kind of PCBAs can SME-6200 clean?
A1: All kinds of solder paste PCBA.
Q2: Can SME-6200 clean PCBA very clean?
A2: Yes, normally we heat liquid and DI water to 60℃ and we have up and down 2x10 spray rods with diffirent type of spray nozzles.So it can clean very well, some of our customer are using SME-6200, they like it very much.
Q3: What is the DI water temperature?
A3: DI water can heat to 60℃.
Q4: What is the DI water consumption per hour?
A4: It depends temperature, normally 5~10L/ Hour.
